EOS R5 Firmware Update, Version 1.6.0 [macOS]

    15-Jul-2022
    0400764607

    Download

    I have read and understood the disclaimer below
    and wish to download the designated software

    OS

    • macOS 12
    • macOS 11
    • macOS 10.15
    • macOS 10.14

    Detail

    Firmware Version 1.6.0 incorporates the following enhancements and fixes:
    1. Adds [Auto Power Off Temp.: Standard/High] to the menu for movie recording. When [High] is selected, the camera will not automatically turn off when the temperature of the camera body and card become high, which may allow for longer movie recording than before, depending on the shooting conditions. Note that the temperature of the bottom surface of the camera may increase at this time.
    2. Adds the ability to convert multiple HEIF images into multiple JPEG images.
    3. Enhances the performance of "Movie Digital IS". It stabilizes the image when taking selfies or walking shots using a wide-angle lens.
    4. Fixes minor issues.

    If the camera's firmware is already Version 1.6.0, it is not necessary to update the firmware.

    Notes:
    Users manual in the WEB is updated accordingly. Please download the manual as well as the latest firmware. You can download it from the official WEB site.

    Preparations for a firmware update:
    After the downloaded compressed file (.dmg file) is extracted, a firmware folder is created.

    *Extracting the downloaded file:
    The downloaded folder is automatically extracted, and a firmware folder is created. If the download folder cannot be automatically extracted, double-click the folder.

    In the folder you downloaded are the firmware ( EOSR5160.FIR / file size: 53,151,472 bytes) and instructions on the firmware update procedures (a PDF file in five languages: Japanese, English, French, Spanish, and Simplified Chinese). Before starting the firmware update operations, please be sure to check the procedure in accordance with the instruction.

    (The following is the history of past firmware updates.)
    Changes in version 1.5.2:
    1. Optimizes AutoFocus accuracy when Extender RF1.4x or Extender RF2x is attached to the RF800mm F5.6 L IS USM and RF1200mm F8 L IS USM lenses.
    2. Enhances the stability of Eye Detection.
    3. Enhances AutoFocus tracking when shooting moving subjects.

    Changes in version 1.5.1:
    1. Fixes an issue that in rare instances, the camera may become inoperable when shooting in the Servo AF setting while operating the <AF-ON> button.

    Changes in version 1.5.0:
    1. Improves head detection performance to support helmets or goggles in winter sports.
    2. Adds [Vehicles] selection to [Subject to detect] selection in the [AF] tab to support the detection of automobiles and motorcycles in motorsports. Adds [Spot detection] when [Vehicles] is selected as the helmet of the driver or rider*.
    *Detection may not be possible for ordinary passenger cars or bicycles, or for motorcyclists performing stunts or kicking up dirt and dust.
    3. Improves detection performance for eye detection when:
    -there are shadows on the face.
    -hair is hanging over the eyes.
    4. Adds support for torso detection of a person. If the eyes, face or head are hidden or cannot be detected, a person's torso will be detected and tracked continuously.
    5. Adds the ability to import manual white balance (MWB) data from the Quick Control screen when capturing still images.
    6. Eliminates the center press operation of the multi-controller to prevent accidentally transferring images during FTP transfer.
    7. Adds the ability, when using EOS Utility for remote shooting with two cards inserted, to set the recording method and to select which card to be recorded to.
    8. Adds [Suppress lower frame rate] to [Smooth] in [Disp. performance], enabling the shooting screen to be displayed with less drop frame rate even in dark locations.
    9. Adds support for the RF 5.2mm F2.8 L Dual Fisheye lens.
    10. Changes the default value of [FTP server] → [Passive mode] to [Enable].
    11. Improves operation stability during FTP transfer.
    12. Optimizes controls of In-Body Image Stabilization (IBIS) when using specific EF lenses not equipped with the image stabilization function.
    13. Fixes an issue, in which noise occurs along the edges of bright subjects when using Canon Log for movie recording.

    Changes in version 1.4.0:
    1. Adds support for outputting 8K/30p/10-bit video signals for ProRes RAW recording to ATOMOS's Ninja V+ recorder* via HDMI.
    * If you have any questions about ATOMOS products, please contact ATOMOS directly.
    * Please note that the recorder may become hot.
    2. Adds support for movie recording when the camera is connected to the CN-E18-80mm T4.4 L IS KAS S or CN-E70-200mm T4.4 L IS KAS S EF cinema lenses.
    * Still photography shooting is possible however performance is not guaranteed.
    * Movie shooting in vertical position is possible however performance is not guaranteed.
    * External power supply is required for AF operation during servo zoom operation. When there is no external power supply, AF operation is activated only when the servo zoom is not in use.
    3. Adds simultaneous movie recording capability on card 1 and card 2, however RAW movies and RAW(Light) movies cannot be recorded simultaneously on card 1 and card 2.
    4. Adds support for the VPG 400 (Video Performance Guarantee Profile), a standard based on the CFexpress 2.0 specification.
    5. Improves operation stability when using the RF400mm F2.8 L IS USM and RF600mm F4 L IS USM.
    6. Fixes an issue in which, during HDMI connection, if the camera's screen turns off, a zebra pattern is displayed via the HDMI output.
    7. Fixes an issue in which sufficient image stabilization effects may not be attained immediately after the start of shooting.

    Changes in version 1.3.1:
    1. Adds [Canon Log 3] to [Canon Log settings]. You can select [Canon Log] or [Canon Log 3] from [Canon Log settings] in the Shooting tab of the menu.
    - Support for RAW movies shot with Canon Log3 and RAW (Light) will be available in Cinema RAW Development and in Digital Photo Professional version in a future update.
    - Digital Photo Professional will also support the processing of RAW movies shot in Canon Log3 settings and the application of Viewing LUT in a future update.
    2. Adds [RAW (Light)] to the movie recording size and [IPB (Light)] to 8K/4K to enable lower bit rate shooting. These settings can also be selected when RAW+MP4 is set.
    3. Adds a high frame rate of 119.9 fps/100.0 fps to the Full HD movie recording size.
    4. Adds [Electronic full-time MF] to the AF tab of the menu. When a lens is attached, manual focus adjustment is always possible with both One-shot AF and Servo AF.
    5. Adds [6: Monitor Off] to [Shooting info. disp.: Screen info. settings] in the Shooting tab of the menu. This update makes it possible for the camera's monitor to be turned off at all times during shooting.
    6. The transfer time (estimated value) now displays on the camera monitor during FTP transfer.
    7. Adds the ability, when transferring images via FTP, to select protected images that failed to be transferred and protected images that have not yet been transferred and transfer them all at once.
    8. Adds [Save/load cam settings on card] to the Function settings tab of the menu.
    This allows you to save the camera settings to a card, or load a saved file and restore the camera to the settings you saved to a card.
    9. Fixes a phenomenon, in which, in rare instances, the camera does not function normally when using certain CFexpress cards.
    10. Fixes a phenomenon, in which in rare instances, the camera cannot function normally when the drive mode is set to "High-speed continuous shooting" to shoot still images continuously.
    11. Fixes a phenomenon in which the power may become suspended when the camera is powered via USB for an extended period of time.
    12. Fixes a phenomenon, in which part of the settings screen is incorrectly displayed in Firmware Version 1.2.1.
    13. Fixes a phenomenon, in which when shooting with Canon Log 3, if the [View Assist.] setting is set to [On], the image in the viewfinder and on the LCD screen is displayed brighter than it should be.
    *Items 1 through 12 apply to Version 1.3.0, whereas Item 13 applies to Version 1.3.1.

    Changes in version 1.2.0:
    1. When using high-speed or low-speed continuous shooting modes, in Drive Mode with [High Speed Display: OFF], the visibility of the subject within the frame has been improved when shooting moving objects.*
    *During continuous shooting black frames will be inserted between frames in the viewfinder and live view. This will improve the visibility of moving subjects in live view and in the viewfinder.
    2. Adds the [Auto] setting to the [Viewfinder brightness] menu that will brighten and dim based on ambient light conditions.
    3. Enables 2nd curtain shooting sync during radio transmission wireless flash shooting when the Speedlite EL-1 flash is attached to the camera.
    4. Enables manual flash output (excluding high-speed sync and optical transmission wireless flash shooting) to be selected and set up to 1/8192 from the camera menu screen when the Speedlite EL-1 flash is attached to the camera.
    5. Improves compatibility of HEIF images recorded in the camera with MIAF (Multi-Image Application Format) standards.
    6. Adds support for AF and release during zoom operations for some RF and EF lenses.

    Changes in version 1.1.1:
    1. A messaging is displayed when [HDMI display: Camera+External monitor] and [Overheat control: on] settings are both enabled.
    2. When the RF100-500mm F4.5-7.1 L IS USM is attached, an image stabilization effect of approximately six stops is achieved through collaborative control with the in-lens image stabilization.
    *Focal length 500mm, Based on CIPA(Camera & Imaging Products Association) standards.
    3. Fixes a phenomenon in which the IS capabilities may be degraded when performing continuous shooting in cases where the RF100-500mm F4.5-7.1 L IS USM lens is attached to the EOS R6 running firmware version 1.1.0.
    4. When using certain RF lenses for movie shooting, the in-lens image stabilization mechanism has been improved.
    5. Fixes a phenomenon in which the "Slow Synchro" setting screen is not accurately displayed, when the language is set to English.
    6. Fixes a typo displayed on the communication setting screen, when the language is set to Korean.
    7. Connectivity during FTP transmission has been improved.
    8. Temperature detection and shooting time control in video shooting have been improved. In addition, the total shooting time when the short-time recording and power-on/off are performed repeatedly at room temperature is improved.
    9. The phenomenon in which the movie recording time available is not correctly displayed when the Date/Time/Zone is not set has been corrected.

    File information

    1. File name : eosr5-v160-mac.dmg
    2. File version : 1.6.0
    3. File type : dmg
    4. File size : 63497KB
