imageFORCE 710 Series
imageFORCE 710 Series
Powerful Performance Designed for Today's Office Demands
The imageFORCE 710 Series brings together high-speed output, advanced connectivity, and a streamlined design tailored for modern workplaces.
Delivering speeds up to 71 ppm and fast first-print output, the imageFORCE 710 Series keeps pace with demanding office tasks while Wi-Fi 6 connectivity brings faster, more reliable wireless performance for effortless integration.
Key Features
Features
Performance You Can Count On
Engineered for optimal performance, with intelligent maintenance tools and long-lasting parts that reduce downtime and maximise uptime.
Stay Secure, Stay In Control
Advanced protection for your data, with features like user authentication and audit logs that help you monitor and mitigate potential risks.
Smart Design Meets Sustainability
Built with up to 20% recycled plastic, supported by eco-friendly packaging and lower energy consumption.
Specifications
Main Unit
| Machine Type | A4 Monochrome Laser Multifunctional |
| Core Functions | Print, Copy, Scan, Send, Store and Optional Fax |
| Processor | Dual Core Processor |
| Control Panel | 10.1" TFT LCD WSVGA Colour Touch panel |
| Memory | RAM: 4.5 GB |
| Storage | SSD (Standard): 256 GB |
| Interface Connection | NETWORK Standard: 1000Base-T/100Base-TX/10Base-T Optional: Wi-Fi (IEEE 802.11a/b/g/n/ac/ax) OTHERS Standard: USB 2.0 (Host) x 1, USB 3.0 (Host) x 1, USB 2.0 (Device) x 1 Optional: Serial Interface, Copy Control Interface |
| Paper Supply Capacity (A4, 80 gsm) | iStandard: 650 sheets 100-sheets Multi-purpose Tray 550-sheets Paper Cassette x 1 Maximum: 3,200 sheets (with High Capacity Cassette Feeding Unit-D1) |
| Paper Output Capacity (A4, 80 gsm) | imageFORCE 710/610/520: 500 sheets |
| Finishing Capabilities | imageFORCE 710/610/520: Collate, Group |
| Supported Media Types | Multi-purpose Tray: Thin, Plain, Recycled, Colour, Heavy, Bond, Transparency, Letterhead, Envelope Paper Cassette: Thin, Plain, Recycled, Colour, Heavy, Bond, Label, Pre-Punched, Letterhead |
| Supported Media Sizes | Multi-purpose Tray: Standard size: A4, A5, A5R, A6, B5 Custom size: 76.2 x 127.0 mm to 216.0 x 355.6 mm Envelope: COM10 No.10, Monarch, DL, ISO-C5 Paper Cassette: Standard size: A4, A5, A5R, A6, B5 Custom size: 99.0 x 148.0 mm to 216.0 x 297.0 mm |
| Supported Media Weights | Multi-purpose Tray: 60 to 200 gsm Paper Cassette: 60 to 135 gsm Duplex: 60 to 120 gsm |
| Warm-up Time | Quick Startup Mode: 4 seconds or less*1 From Power On: 10 seconds or less*2 From Sleep Mode: 10 seconds or less |
| Dimensions (W x D x H) | 500 x 598 x 617 mm |
| Installation Space (W x D) | 1,052 x 823 mm (with left CRG door open + right door open + the cassette drawer open) |
| Weight*3 | Approx. 36 kg including toner |
| Print Speed (BW) | imageFORCE 710: Up to 71 ppm (A4), Up to 113 ppm (A5), Up to 40 ppm (A5R, A6) imageFORCE 610: Up to 61 ppm (A4), Up to 99 ppm (A5), Up to 35 ppm (A5R, A6) imageFORCE 520: Up to 52 ppm (A4), Up to 80 ppm (A5), Up to 35 ppm (A5R, A6)*4 |
| Print Resolution (dpi) | 1,200 x 600 Data processing is 2,400 equivalent x 600, 1,200 x 1,200 equivalent |
| Page Description Languages | Standard: UFR II, PCL6/PCL5, Adobe PostScript 3 |
| Direct Print | Supported file types: PDF, EPS, TIFF/JPEG, and XPS |
| Printing from Mobile and Cloud | AirPrint, Mopria®, IPP Everywhere, Canon PRINT, uniFLOW Online, Universal Print and Cloud Connector |
| OS Standard Printing | Android*5, Windows® 10*5, Windows® 11*5, Chrome OS*5, macOS (11.2.2 or later)*6, iOS (15.2 or later)*6, iPadOS*6 |
| Fonts | PS fonts: 136 Roman PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T*7 (Japanese, Korean, Simplified and Traditional Chinese), Barcode fonts*8 |
| Operating System | UFRII: Windows® 10/11/Server 2016/Server 2019/Server 2022/Server 2025, macOS (10.14 or later) PCL: Windows® 10/11/Server 2016/Server 2019/Server 2022/Server 2025 PS: Windows® 10/11/Server 2016/Server 2019/Server 2022/Server 2025, macOS (10.14 or later) PPD: Windows® 10/11, macOS (10.15 or later) As of Dec. 2024 |
Copy
| Copy Speed (BW) | imageFORCE 710: Up to 71 ppm (A4), Up to 113 ppm (A5), Up to 40 ppm (A5R, A6) imageFORCE 610: Up to 61 ppm (A4), Up to 99 ppm (A5), Up to 35 ppm (A5R, A6) imageFORCE 520: Up to 52 ppm (A4), Up to 80 ppm (A5), Up to 35 ppm (A5R, A6)*4 |
| First-Copy-Out Time (A4, BW) | Approx. 5 seconds or less |
| Copy Resolution (dpi) | 600 x 600 |
| Multiple Copies | Up to 9,999 copies |
| Copy Density | Automatic or Manual (9 Levels) |
| Magnification | Variable zoom: 25% to 400% (1% Increments) |
Scan
| Type | Single-pass Duplexing Automatic Document Feeder [2-sided to 2-sided (Automatic)]*9 |
| Document Feeder Paper Capacity (80 gsm) | Up to 100 Sheets |
| Document Feeder Acceptable Paper Weight | Document Feeder media weight: 1-sided scanning: 42 to 128 gsm (BW), 64 to 128 gsm (CL) 2-sided scanning: 50 to 128 gsm (BW), 64 to 128 gsm (CL) Note: - Business card: 80 to 220 gsm - Original width narrower than A6: 50 to 128 gsm - Long Original (over than 355.6 mm): 60 to 90 gsm |
| Supported Media Sizes | Platen scanning size: Up to 216.0 x 355.6 mm Document Feeder media size: AA4, A5R, A6, B5 Custom size: 48.0 x 128.0 mm to 216.0 x 355.6 mm Business card: 48.0 x 85.0 mm to 55.0 x 91.0 mm |
| Scan Speed (ipm, BW/CL, A4) | Send (300 x 300 dpi): Automatic Colour Select "OFF": 1-sided Scanning: 95 2-sided Scanning: 190 Automatic Colour Select "ON": 1-sided Scanning: 50 2-sided Scanning: 100 Copy (600 x 600 dpi): 1-sided Scanning: 95 2-sided Scanning: 140 |
| Scan Resolution (dpi) | 600 x 600 |
| Pull Scan Specifications | Color Network ScanGear 2 for both TWAIN and WIA Supported OS: Windows® 10/11/Server 2016/Server 2019/Server 2022/Server 2025 As of Dec. 2024 |
Send
| Destination | Standard: E-mail/Internet FAX (SMTP*10), SMB, FTP, WebDAV, Mail Box Optional: Super G3 FAX, IP Fax |
| Address Book | LDAP (2,000)/Local (1,600)/Speed dial (200) |
| Communication Protocol | File: FTP (TCP/IP), SMB3.1.1 (TCP/IP), WebDAV E-mail/I-Fax: SMTP, POP3 |
| File Format | TIFF (MMR), JPEG, PDF (Compact, Searchable, Optimise for Web, PDF/A-1b, Trace & Smooth, Encrypted, Device Signature, User Signature), XPS (Compact, Searchable, Device Signature, User Signature), Office Open XML (PowerPoint, Word) |
Fax
| Maximum Number of Connection Lines | 1 |
| Modem Speed | Super G3: 33.6 kbps G3: 14.4 kbps |
| Compression Method | MH, MR, MMR, JBIG |
| Resolution (dpi) | 400 x 400 (Ultra Fine), 200 x 400 (Super Fine), 200 x 200 (Fine), 200 x 100 (Normal) |
| Sending/Receiving Size | Sending: A4, A5R*11, A6*11, B5*11 Receiving: A4, A5*11, A5R, B5 |
| FAX Memory | Up to 30,000 pages (2,000 jobs) |
| Speed Dials | Max. 200 |
| Group Dials/Destinations | Max. 199 dials |
| Sequential Broadcast | Max. 256 addresses |
| Memory Backup | Yes |
Store
| Mail Box (Number Supported) | 100 User Inboxes 1 Memory RX Inbox 50 Confidential Fax Inboxes Maximum 30,000 Pages (2,000 jobs) Stored |
| Advanced Box | Communication Protocol: SMB or WebDAV Supported Client PC: Windows® 10/11 Concurrent Connections (Max.): SMB: 64, WebDAV: 3 |
| Advanced Box Available Disc Space | Standard: 16 GB |
Security
| Authentication and Access Control | User Authentication (Picture Login, Picture and PIN Login, Card Login, Username and Password Login, Function Level Login, Mobile Login), Department ID Authentication (Department ID and PIN Login, Function Level Login), uniFLOW Online/uniFLOW*12 (PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Department ID and PIN Login, Function Level Login), Microsoft Entra ID Authentication (Password Login, Card Login), Two-Factor Authentication at LUI/RUI, Access Management System (Access Control) |
| Document Security | Print Security (Secure Print, Encrypted Secure Print, Forced Hold Printing, uniFLOW Secure Print*12), Receive Data Security (Confidential Fax Inbox Forwarding Received Documents Automatically), Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS, BOX Security (Mail Box Password Protected, Advanced Box Access Control), Send Data Security (Setting for requesting password input per transmission, Restricted E-mail/File send functions, Confirming FAX number, Allow/Restrict Fax Driver Transmissions, Allow/Restrict Sending from History, S/MIME Support), Secure Watermark |
| Network Security | TLS 1.3 (FIPS140-3), IPSec (FIPS140-3), IEEE802.1X authentication, SNMPv3, Firewall Functionality (IP/MAC Address Filtering), Dual Network Support (Wired LAN/Wireless LAN, Wired LAN/Wired LAN), WPA3 support (Wi-Fi), Enabling/Disabling (Network Applications, Remote UI, USB Interface), G3 FAX separation from LAN, USB Port separation from LAN, Prohibit the execution of files stored in Advanced Box in the MFP, Scan and Send -Virus Concerns for E-mail Reception |
| Device Security | Protecting SSD Data [SSD Data Encryption (FIPS140-3), SSD Lock], Standard SSD Initialize, Initialize (NIST 800-88 PURGE LEVEL), Trusted Platform Module (TPM 2.0), Job Log Conceal Function, Protecting MFP Software Integrity: Verify System at Startup (NIST SP800-193: Protection), Checking MFP Software Integrity & Platform Firmware Resiliency: Automatic System Recovery (NIST SP800-193: Recovery), Runtime Intrusion Detection: Trellix Embedded Control, HCD-PP Common Criteria Certification (Pending Confirmation) |
| Device Management and Auditing | Administrator Password, Digital Certificate And Key Management, SAN certificates, Audit Log, Cooperating with External Security Audit System (Security Information and Event Management), Image Data Logging, Security Policy Setting |
Environmental
| Operating Environment | Temperature: 10 to 30 ºC Humidity: 20 to 80 % RH (Relative Humidity / No condensation) |
| Power Source | 220-240 V, 50/60 Hz, 4.8 A |
| Power Consumption | Maximum: Approx. 1,500 W Sleep mode: Approx. 0.36 W*13 |
Consumables
| Toner Cartridges | T03 Black |
| Toner Yield | T03 Black: Yield: 51,500 (A4) Toner cartridge yield in accordance with ISO/IEC 19752 |
Software and Printer Management
| Tracking and Reporting | uniFLOW Online |
| Remote Management Tools | iW Enterprise Management Console Monitoring Service Remote Distribution & Management Service |
| Scanning Software | Colour Network ScanGear 2 |
| Optimisation Tools | Canon Driver Configuration Tool |
| Platform | MEAP (Multifunctional Embedded Application Platform) |
Paper Supply Options
| Cassette Module-AG1 | Paper Capacity: 550 sheets (80 gsm) Paper Type: Thin, Plain, Recycled, Heavy, Colour, Label, Bond, Pre-punched, Letterhead Paper Size: A4, A5, A5R, A6, B5, Custom size: 99.0 x 148.0 mm to 216.0 x 355.6 mm Paper Weight: 60 to 135 gsm |
| Envelope Cassette Module-A1 | Paper Capacity: 75 sheets (Envelope) Envelope Size: COM10 No.10, Monarch, DL, ISO-C5 Paper Weight: 80 to 100 gsm |
| Cassette Feeding Unit-AR1 | Paper Capacity: 550 sheets (80 gsm) Paper Type: Thin, Plain, Recycled, Heavy, Colour, Label, Bond, Pre-punched, Letterhead Paper Size: A4, A5, A5R, A6, B5, Custom size: 99.0 x 148.0 mm to 216.0 x 355.6 mm Paper Weight: 60 to 135 gsm |
| High Capacity Cassette Feeding Unit-D1 | Upper Cassette: Paper Capacity: 550 sheets (80 gsm) Paper Type: Thin, Plain, Recycled, Heavy, Colour, Label, Bond, Pre-punched, Letterhead Paper Size: A4, A5, A5R, A6, B5, Custom size: 99.0 x 148.0 mm to 216.0 x 355.6 mm Paper Weight: 60 to 135 gsm Lower Cassette: Paper Capacity: 2,000 sheets (80 gsm) Paper Type: Thin, Plain, Recycled, Heavy, Colour, Bond, Pre-punched Paper Size: A4 Paper Weight: 60 to 135 gsm |
| Cassette Feeding Unit-AX1 | Paper Capacity: 1st cassette 550 sheets (80 gsm) 2nd cassette 550 sheets (80 gsm) 3rd cassette 550 sheets (80 gsm) Paper Type: Thin, Plain, Recycled, Heavy, Colour, Label, Bond, Pre-punched, Letterhead Paper Size: A4, A5, A5R, A6, B5, Custom size: 99.0 x 148.0 mm to 216.0 x 355.6 mm Paper Weight: 60 to 135 gsm |
- Time from device power-on to when the copy icon appears and is enabled to operate on the touch panel display.
- Time from device power on, until copy ready (not print reservation).
- Including regular toner.
- 1-sided only.
- Need to select the [Use Mopria®] check box [OK].
- Need to select the [Use AirPrint] check box [OK].
- Optional PCL International Font Set-A1 is required.
- Optional Barcode Printing Kit-D1 is required.
- Detect Feeder Multi Sheet Feed is supported.
- Available OAuth 2.0 authentication method on Microsoft 365 and Google Workspace.
- Sent as A4.
- Optional.
- 0.36 W sleep mode is not available in all circumstances due to certain settings.
