Main Unit


A3 Monochrome Laser Multifunctional

Core Functions

Print, Copy, Scan, Send, Store and Optional Fax


Canon Dual Custom Processor (Shared)

Control Panel

Standard: 10.1 inch TFT LCD WSVGA Color Touch panel
Optional: 10.4 inch TFT LCD SVGA Color Upright Touch panel


Standard: 3.0 GB RAM

Hard Disk Drive

Standard: 320GB (Available disk space: 250GB)
Maximum: 1TB

Mirroring Hard Disk Drive

Optional: 250GTB, 1TB

Interface Connection

Standard: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n);
Optional: NFC, Bluetooth Low Energy

Standard: USB 2.0 (Host) x2, USB 3.0 (Host) x1, USB 2.0 (Device) x1;
Optional: Serial Interface, Copy Control Interface

Paper Supply Capacity (A4, 80 gsm)

Standard: 4,200 sheets ( 2 x 1,500-sheet cassette, 2 X 550-sheet cassette, 100-sheet Multi-purpose tray)
Maximum: 7,700 sheets (with POD Deck Lite-C1 or Paper Deck Unit-E1)

Paper Output Capacity (A4, 80 gsm)

250 Sheets (with Copy Tray-R2)
Maximum: 3,500 Sheets (with Staple Finisher-V2 or Booklet Finisher-V2)

Finishing Capabilities

Standard: Collate, Group
With External finisher: Collate, Group, Offset, Staple, Saddle Stitch*1, Hole Punch*2, ECO-Staple*3, Staple-on-Demand*3, Document Insertion*4, Fold (C-, Z- folding*5)

Supported Media Types

Upper Left/Right Cassettes (1/2):
Thin, Plain, Recycled, Colour, Thick, Pre-punched, Letterhead, Bond

Lower Cassettes (3/4):
Thin, Plain, Recycled, Colour, Thick, Pre-punched, Letterhead, Bond paper, Tab*6

Multi-purpose tray:
Thin, Plain, Recycled, Colour, Thick, Pre-punched, Bond, Transparency, Labels, Letterhead, Tab, Tracing*7

Supported Media Sizes

Upper Left/Right Cassettes (1/2):
Standard size: A4, B5

Lower Cassettes (3/4):
Standard size: A3, A4, A4R, A5R, B4, B5, B5R
Custom size: 139.7 x 182.0 mm to 297.0 x 487.7 mm

Multi-purpose tray:
Standard size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
Custom size: 100.0 x 148.0 mm to 297.0 x 487.7 mm
Free size: 100.0 x 182.0 mm to 297.0 x 487.7 mm

Supported Media Weights

Paper Cassettes: 52 to 220 gsm
Multi-purpose tray: 52 to 256 gsm
Duplex: 52 to 220 gsm

Warm-up Time

From Power On: 30 seconds or less*8
From Sleep Mode: 30 seconds or less
Quick Startup Mode: 4 seconds or less*9

Dimensions (W x D x H)

Standard: 670 x 779 x 1,220 mm
With optional Upright Touch Panel: 1,481 x 770 x 1,252 mm

Installation Space (W x D)

Basic: 1,533 x 1,353 mm (with Multi-purpose tray/Upper-right cover open + Front cover open + Copy Tray)
Fully configured: 2,436 x 1,353 mm (with POD Deck Lite-C1 + Document Insertion / Folding Unit-J1 + Booklet Finisher-V2 or Staple Finisher-V2 + Main unit Front cover open)


Standard (with flat touch panel) Approx. 234 kg*10,
With optional Upright touch panel: Approx. 238 kg*10


Print Speed (ppm)

iR-ADV 6575i III
Up to 37 (A3), up to 75 (A4), up to 54 (A4R), up to 35 (A5R)

iR-ADV 6565i III
Up to 32 (A3), up to 65 (A4), up to 47 (A4R), up to 35 (A5R)

iR-ADV 6555i III
Up to 32 (A3), up to 55 (A4), up to 40 (A4R), up to 35 (A5R)

Print Resolution (dpi)

Data processing resolution: 1,200 x 1,200, 600 x 600
Output resolution: 1,200 x 1,200

Page Description Languages

Standard: UFR II (standard), PCL 6
Optional: Adobe PS 3

Direct Print

Available from USB memory, Advanced box, Remote UI and Web Access*11
Supported File Types: PDF, TIFF, JPEG, EPS and XPS

Printing from Mobile and Cloud

AirPrint, Mopria, Google Cloud Print, and Canon Business Print, and uniFLOW Online


PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WTJ/K/S/T*12 (Japanese, Korean, Simplified and Traditional Chinese), Barcode fonts*13
PS fonts: 136 Roman

Operating System

UFRII: Windows 7 / 8.1 /10 / Server 2008 / Server 2008 R2 / Server 2012 / Server 2012 R2 / Server 2016, MAC OS X ( 10.9 or later)
PCL: Windows 7 / 8.1 / 10 / Server 2008 / Server 2008 R2 / Server 2012 / Server 2012 R2 / Server 2016
PS: Windows 7 / 8.1 / 10 / Server 2008 / Server 2008 R2 / Server 2012 / Server 2012 R2 / Server 2016, MAC OS X (10.9 or later)
PPD: MAC OS X (10.3.9 or later), Windows 7 / 8.1/ 10




Single-pass Duplexing Automatic Document Feeder

Document Feeder Paper Capacity (80 gsm)

300 Sheets

Acceptable Originals and Weights

Platen: Sheet, Book, 3-Dimensional Objects (Height: Up to 50 mm, Weight: up to 2kg)

Document Feeder Media weight:
1-sided scanning: 38 to 220 gsm (BW), 64 to 220 gsm (CL)
2-sided scanning: 50 to 220 gsm (BW), 64 to 220 gsm (CL)

Supported Media Sizes

Platen: Max. scanning size: 297 x 431.8 mm
Document Feeder media size: A3, A4, A4R, A5, A5R, B4, B5, B5R, B6R
Custom size: 128.0 x 139.7 mm to 304.8 x 431.8 mm

Scan Speed (A4, BW/CL)

1-sided Scanning (ipm): 120/120 (300 dpi, Send), 120 (600 dpi, BW Copy)
2-sided Scanning (ipm): 240/220 (300 dpi, Send), 150 (600 dpi, BW Copy)

Scan Resolution (dpi)

600 x 600, 400 x 400, 300 x 300, 200 x 400, 200 x 200, 200 x 100, 150 x 150, 100 x 100

Pull Scan Specifications

Colour Network ScanGear2. For both Twain and WIA
Supported OS: Windows 7 / 8.1 / 10 / Server 2008 / Server 2008 R2 / Server 2012 / Server 2012 R2 / Server 2016



Optional / Standard

Optional on all models

Maximum Number of Connection Lines


Modem Speed

Super G3: 33.6 kbps
G3: 14.4 kbps

Compression Method


Resolution (dpi)

400 x 400, 200 x 400, 200 x 200, 200 x 100

Sending / Recording Size

A3, A4, A4R, A5*14, A5R*14, B4, B5*15, B5R*14

FAX / Memory

Up to 30,000 pages

Speed Dials

Max. 200

Group Dials / Destinations

Max. 199 dials

Sequential Broadcast

Max. 256 addresses

Memory Backup



Mail Box (Number supported)

100 User Inboxes, 1 Memory RX Inbox,
50 Confidential Fax Inboxes,
30,000 Maximum Pages Stored

Advanced Box

Communication Protocol: SMB or WebDAV
Supported Client PC: Windows (Windows 7 / 8.1 / 10)
Concurrent Connections (Max.): SMB: 64, WebADV: 3 (Active Sessions)

Advanced Box Available Disc Space

Approx. 16GB (Standard HDD)
Approx. 480GB (with option 1TB HDD)

Memory Media

Standard: USB Memory



Standard: User Authentication (Picture Login/Keyboard Authentication), DepartmentID Authentication,  Access Management System, uniFLOW Online Express Cloud based management software
Optional: My Print Anywhere secure print (Requires uniFLOW)


Standard: Trusted Platform Module (TPM), Hard Disk Password Lock, Hard Disk Drive Erase, Mail Box Password Protection, Hard Disk Drive Encryption(FIPS140-2 Validated)
Optional: Hard Disk Drive Mirroring, Hard Disk Drive removal, IEEE 2600.2 Common Criteria Certification, Data Loss Prevention (Requires uniFLOW,iWSAM Express)


Standard: IP/Mac Address Filtering, IPSEC, TLS Encrypted Communication, SNMP V3.0, IEEE 802.1X, IPv6, SMTP Authentication, POP Authentication before SMTP, S/MIME


Standard: Secure Print, Adobe LiveCycle® Rights Management ES2.5 Integration, Encrypted PDF, Encrypted Secure Print, Device signature, Secure Watermarks
Optional: User signature, Document Scan lock


Operating Environment

Temperature: 10 to 30 ºC
Humidity: 20 to 80 % RH (Relative Humidity)

Power Requirements

220-240V(±10 %), 50/60Hz (±2 Hz), 10Amp

Power Consumption

Maximum: Approx. 2,400 W
Standby: Approx. 260.4 W*16
Sleep mode: Approx. 0.9 W*17


Fiery Print Controller Specifications (External)

Paper Supply Options

Hardware Accessories

Security Options

System and Controller options

Other Options

  1. Requires Booklet Finisher-V2.
  2. Requires 2/3 Hole Puncher Unit-A1 or 2/4 Hole Puncher Unit-A1 (with Staple Finisher-V2 or Booklet Finisher-V2).
  3. Requires Staple Finisher-V2 or Booklet Finisher-V2.
  4. Requires Document Insertion Unit-P1 or Document Insertion/Folding Unit-J1 (with Staple Finisher-V2 or Booklet Finisher-V2 ).
  5. Requires Document Insertion/Folding Unit-J1 (with Staple Finisher-V2 or Booklet Finisher-V2).
  6. Requires Tab Feeding Attachment-B1.
  7. Some types of tracing paper cannot be used.
  8. Time from device power-on, until copy ready.
  9. Time from device power-on to when key operations can be performed on the touch panel display.
  10. Including ADF and the toner bottle.
  11. Only PDF print from websites is supported.
  12. Requires optional PCL International Font Set-A1.
  13. Requires optional Barcode Printing Kit-D1.
  14. Sent as A4.
  15. Sent as B4.
  16. Reference value: measured one unit.
  17. 0.9W sleep mode may not be possible in all circumstances due to certain settings.
